Description

ASALAIR CARBO 1800 F.A. EXHAUST HOOD

Code: 29940034

Product Description

The Asalair Carbo 1800 F.A. Exhaust Hood is a bench chemical hood with molecular filtration featuring a activated carbon filter, designed to ensure high protection for the operator and the environment during manipulations that generate toxic vapors, solvents, and foul-smelling substances.

It is suitable for chemical, environmental, school, university laboratories, and healthcare facilities where protection from external contamination is not required.

The dual suction system allows for effective extraction of both heavy and light vapors, maintaining a constant protective barrier even as the panel opening changes.

Filtration System

F.A. version = activated carbon filter for generic substances

Configuration 1800 F.A.: 10 + 10 + 10 kg of activated carbon

Removable pre-filter class ePM10 50% (EN ISO 16890:2016)

Possibility of impregnated filter (ammonia, formaldehyde, acid gases, iodine, mercury)

Provision for HEPA H14 filter (99.995%)

Construction Features

Structure made of steel with acid-resistant coating RAL 9010

Work surface in satin AISI 316L stainless steel, removable

Side and front panels in plexiglass

Motorized front panel (opening 250–650 mm)

3 low-noise fans

Two-speed suction control

Emergency button for maximum suction

LED lighting 19–35 W – 1000 Lux

Display of filter operating hours (max 9999 h)

Service socket with programmable timer

Noise level ≤ 60 dB

Specific Technical Data – 1800 F.A.

Feature	Value
Working area dimensions	1750 × 600 × 770 mm
Basin capacity	12 liters
External dimensions	1885 × 780 × 1500 mm
Dimensions with duct	1885 × 780 × 1670 mm
Filtered air volume	800 m³/h
Average air speed	0.5 m/s
Weight	300 kg

Electrical Data

Power supply: 230 V – 50 Hz

Power consumption: 420 W + 440 W

Fuses: 2 × 5 AF (5×20 mm)

Network connection socket: 10 A

Protection class: I

Standards and Compliance

Compliant with:

Directive 2014/35/EU (Low Voltage)

Directive 2014/30/EU (Electromagnetic Compatibility)

Directive 2006/42/EC (Machinery)

CEI EN 61010-1

UNI EN 14175-1-2-3

EN 61326-1

D.Lgs. 81/08

TÜV certification and Factory Acceptance Test available.

Available Accessories on Request

External discharge duct Ø 200 mm

Water / gas / air taps

Work surface in polypropylene or ceramic gres

Stainless steel sinks with drainage

Dedicated support with wheels

Metal drawer unit

Intended Use

Industrial chemical laboratories

University laboratories

Environmental analysis

Handling of solvents and organic/inorganic substances

Applications with high workload

Technical specifications

Material	Acciaio, Acciaio nichel-cromo medicale, Polipropilene
Weight	300 kg
Product Type	Cappa Aspirante
External Dimensions	1885 × 780 × 1500 mm
Voltage	230 V

Documenti

Asalair Carbo 1800 F.A. Fume Hood

Vendor: ASAL

Code: AS29940034

€8.648,20

Tax excluded.

10550.80 Tax included

Regular price ~~€9.827,50~~ -12%

Shipped in 5-10 business days

Free shipping on orders over €199.99
Secure and fast payments
