Product Sheet: XS Sensor Polymer TIP (soils) S7

Description:
Combined pH electrode with a tip membrane, specifically designed for pH measurement in soil. Equipped with an S7 screw head and a glass body for general use. The dimensions are 120 mm in length and 12 mm in diameter, with a cylindrical membrane. The filling is polymer without a porous septum, ensuring a fast and accurate response even in samples that could contaminate traditional diaphragms. This electrode is maintenance-free.

Technical Specifications:

•
  Application: Measurements in soil



•
  Connection: S7 screw head



•
  Body: Glass



•
  Filling: Polymer without porous septum



•
  Dimensions (LxØ): 120x12 mm



•
  pH Measurement Range: 0 - 14 pH



•
  Temperature Measurement Range: -10 - 80 °C



•
  Diaphragm: Open pore



•
  Body Diameter: 12 mm



•
  Body Length: 120 mm



•
  Body Material: Glass



•
  Number of Diaphragms: 2



•
  Reference System: Encapsulated Ag/AgCl


Additional Features:
A renowned Swiss manufacturer has developed a comprehensive range of laboratory pH, Redox electrodes, and conductivity cells, available with both glass and plastic bodies. The new XS sensors are available with an S7 head or a fixed cable with a BNC or DIN connector. Many models intended for the food sector include a built-in temperature sensor for rapid temperature compensation. Some electrodes have the serial number indelibly printed internally and are supplied with a GLP-compliant quality certificate.

Advantages:

•
  High Accuracy: Thanks to the polymer filling and tip membrane, it offers precise measurements even in difficult conditions.



•
  Maintenance-Free: Does not require periodic maintenance.



•
  Contamination Resistance: Designed to resist sample contamination, ensuring long life and reliability.


This electrode is ideal for professionals who need reliable and accurate measurements in the agricultural and environmental sectors.
