The MD 200 COD/CSB Photometer from the GIORGIO BORMAC brand is a compact instrument with an ergonomic design, ideal for precise and reliable measurements. Equipped with a backlit LCD display, this photometer is perfect for laboratories and field applications.

Main Features

The MD 200 COD/CSB Photometer is designed to deliver excellent performance in a compact format. Its features include:

• Temperature-compensated LEDs (430/605 nm)


• Protected sample compartment


• Measurement time of about 3 seconds


• Automatic switch-off after 5 minutes from the last command


• Powered by 4 AA batteries


• Carrying case and instruction manual included

This photometer is compatible with AQUALYTIC Test Tubes (16 mm diameter) and offers a wide measuring range: 0-150 / 0-1500 / 0-15000 mg/l.

Technical Specifications

Performance

• Photometric accuracy: 3% FS (T=20°C - 25°C)


• Wavelength accuracy: ± 1 nm


• Photometric resolution: 0.01 A


• Operating temperature: from 5°C to 40°C


• Operating humidity: from 30% to 90%

Additional Features

• Date and time: Real time and date


• Display: Backlit LCD (at the press of a button)


• Protection rating: IP 68


• Communication interfaces: Infrared (IR) for measurement data transfer


• Interference filter wavelength ranges: 430 nm - 610 nm


• Memory: Internal circular memory for 16 data series


• Optics: LED, interference filters (IF) and photosensor


• Adjustment: Manufacturer and user adjustment, possible at any time


• Automatic switch-off: After 10 minutes from the last button press


• Operating time: 53 hours

Power Supply

The MD 200 COD/CSB Photometer is powered by 4 AAA batteries, ensuring excellent battery life and easy battery replacement.

Dimensions and Weight

The compact dimensions of the photometer (190 x 110 x 55 mm) and the weight of about 455 g (with batteries) make it easy to transport and use in various working conditions.
